MTDY Telecentric Lens Fixed Magnification Series
◆ Telecentric Lens is that placed aperture diaphragm on image space focal plane of optical system.
◆ When aperture diaphragm on image space focal plane, even object distance changes and image distance changes, image height doesn’t changes, then object size of measure will not change.
◆ Telecentric Lens is applied in industry precision measurement. Distortion is very small. High-powered one can have no distortion.
1. MTDY Object Space Telecentric Lens model and specification gather (working distance: 65mm)ModelObjective magnification
Working distance (mm)
Total magnification
Field of video (mm)
NA
Resolution (μm)
Depth of field(mm)
Distortion
1/3"、9"
1/3"、17"
0.8X
65
30.5X
57.6X
6X4.5
0.03
11.2
1.67
0.09%
0.8X
65
30.5X
57.6X
6X4.5
0.03
11.2
1.67
0.09%
1X
65
38.1X
72X
4.8X3.6
0.032
10.5
1.25
0.13%
1X
65
38.1X
72X
4.8X3.6
0.032
10.5
1.25
0.13%
2X
65
76.2X
43.9X
2.4X1.8
0.05
6.7
0.4
0.3%
2X
65
76.2X
43.9X
2.4X1.8
0.05
6.7
0.4
0.3%
3X
65
114.3X
215.9X
1.6X1.2
0.06
5.6
0.22
0.22%
3X
65
114.3X
215.9X
1.6X1.2
0.06
5.6
0.22
0.22%
4X
65
152.4X
287.9X
1.2X0.9
0.039
8.6
0.26
0.24%
4X
65
152.4X
287.9X
1.2X0.9
0.039
8.6
0.26
0.24%
2. MTDY Object Space Telecentric Lens model and specification gather (working distance: 115mm)ModelObjective magnification
Working distance (mm)
Total magnification
Field of video (mm)
NA
Resolution (μm)
Depth of field(mm)
Distortion
1/3"、9"
1/3"、17"
0.5X
115
19.1X
36X
9.6X7.2
0.02
16.8
4
0.1%
0.5X
115
19.1X
36X
9.6X7.2
0.02
16.8
4
0.1%
0.8X
115
30.5X
57.6X
6X4.5
0.03
11.2
1.67
0.6%
0.8X
115
30.5X
57.6X
6X4.5
0.03
11.2
1.67
0.6%
1X
115
38.1X
72X
4.8X3.6
0.032
10.5
1.25
0.3%
1X
115
38.1X
72X
4.8X3.6
0.032
10.5
1.25
0.3%
2X
115
76.2X
143.9X
2.4X1.8
0.04
8.4
0.5
0.17%
2X
115
76.2X
143.9X
2.4X1.8
0.04
8.4
0.5
0.17%
3X
115
114.3X
215.9X
1.6X1.2
0.05
6.7
0.266
0.17%
3X
115
114.3X
215.9X
1.6X1.2
0.05
6.7
0.266
0.17%
4X
115
152.4X
287.9X
1.2X0.9
0.053
6.3
0.188
0.16%
4X
115
152.4X
287.9X
1.2X0.9
0.053
6.3
0.188
0.16%
Note:
1. The depth of field is the value of parsing images if you use 1/2" CCD camera and monitor of level 320 line.(imaging surface concessional confusion circumference: 40μm)
2. Resolution is the theory resolution of wavelength in 550nm.
3. The largest compatible CCD: 1/2"
4. Install dimension: C-mount, the whorl is 1 inch 32 button.
5. In the line of total magnification, “1/3"” is expressed CCD camera's specifications, “9"”、“14"” is expressed monitor's screen dimensions. “1/3"、9"” is expressed the total magnification of MTDY series Object Space Telecentric Lens in 1/3" CCD camera and 9" monitor.
-
-
-
-
-
-
-
-
-
-
-
